| Model | Parameter |
Remark |
| MPPT voltage range |
250V-950V |
|
| Full load voltage range |
580V-700V |
DC voltage - PV voltage>20V |
| MPPT quantity |
Channel 8 |
The device supports up to 12 units and can be configured with 2x PV |
| Max photovoltaic power(kW) |
780kW |
|
| Maximum current per MPPT channel |
168A |
|
| Maximum short-circuit current per MPPT channel |
210A |
|
| MPPT Maximum Tracking Accuracy |
≥99.9% |
|
| Model | Parameter |
Remark |
| Rated power(KW) |
520kW |
|
| Full load voltage range |
650V-950V |
|
| Maximum current |
880A |
|
| Model | Parameter |
Remark |
| Rated power |
1380kW |
|
| Rated voltage |
400V |
Range 340-460V |
| Rated current |
1504A |
Maximum 2000A |
| Rated frequency |
50Hz/60Hz |
Range ±5Hz |
| Power factor |
>0.99 |
|
| THDi |
<1.5%(100% PN) , <5%(≥20%PN) |
|
| Model | Parameter |
Remark |
| Rated power |
520kW |
|
| Rated voltage |
400V |
Range 340-460V |
| Rated current |
752A |
|
|
Rated frequency |
50Hz/60Hz |
|
|
THDu |
1% |
Linear load |
|
Unbalanced load capability |
100% |
|
|
Overload capacity |
110%: Long-term operation; 120%: at least 1 minute 150%: Not less than 1 second(at a constant temperature of 35°C) |
|
| Model | Parameter |
Remark |
| Ambient temperature range |
-30°C~70°C Full power operation at an ambient temperature of 50°C; derating operation at an ambient temperature of 50-70°C; Start-up supported at -30°C. |
|
| Storage temperature range |
-40°C~75°C |
|
| AC/DC surge protection |
TYPE II |
|
|
Cooling method |
Intelligent air cooling |
|
|
Permissible altitude |
4000m(Derating above 3000m) |
|
|
Relative humidity |
0~95%(no condensation) |
|
|
Protection grade |
IP55 | |
|
Noise Level |
<75dB |
|
|
Isolation methods |
Non-isolation |
|
|
Maximum efficiency |
97% |
|
|
On/Off-grid Switching Time |
<20ms |
|
|
Dimensions(W*D*H) |
2200*1350*2300 |
|
|
Weight |
2500kg |
Current estimated weight |
|
Display method |
7-inch industrial LCD touchscreen HMI |
Standard configuration |
|
Local Communication methods |
RS-485/CAN/Enet |
4G & other technologies require customers to provide their own routers |
|
Communication Protocol |
RTU/CAN2.0B/TCP |
|
